ASTM A213 T12 Alloy Steel Seamless Tubes Hot / Cold Finished
Condition
TIPTOP can offer customers with high quality of ASTM A213 seamless
ferritic alloy steel heat exchanger tubes with black painting,
anti-corrosion oil and galvanized finish. Meanwhile, some key
applications for chrome moly ASTM A213/ ASME SA213 T2, T11, T22,
T91, T92 steel tubes are manufacturing boilers, super heaters, heat
exchangers, and so on.
1. Standard:
ASTM A213 Standard Specification for Seamless Ferritic and
Austenitic Alloy-Steel Boiler, Superheater, and Heat-Exchanger
Tubes
2. Ordering Information
Quantity (feet, meters, or number of lengths),
Name of material (seamless tubes),
Grade (T2, T5, T9, T11, T12, T22, T91, and T92),
Condition (hot finished or cold finished),
Size (outside diameter and minimum wall thickness),
Length (specific or random),
Hydrostatic Test or Nondestructive Electric Test
Increased Sulfur, and
Special requirements and any supplementary requirements selected.
3. Chemical Requirements
| Chemical Requirements |
| Grade | UNS Designation | Composition, % |
| C | Mn | p | S | Si | Cr | Mo | Other Elements |
| max | max |
| T2 | K11547 | 0.10-0.20 | 0.30-0.61 | 0.025 | 0.025 | 0.10-0.30 | 0.50-0.81 | 0.44-0.65 | |
| T5 | K41545 | 0.15 max | 0.30-0.60 | 0.025 | 0.025 | 0.50 max | 4.00-6.00 | 0.45-0.65 | |
| T9 | K90941 | 0.15 max | 0.30-0.60 | 0.025 | 0.025 | 0.25-1.00 | 8.00-10.00 | 0.90-1.10 | |
| T11 | K11597 | 0.05-0.15 | 0.30-0.60 | 0.025 | 0.025 | 0.50-1.00 | 1.00-1.50 | 0.44-0.65 | |
| T12 | K11562 | 0.05-0.15 | 0.30-0.61 | 0.025 | 0.025 | 0.50 max | 0.80-1.25 | 0.44-0.65 | |
| T22 | K21590 | 0.05-0.15 | 0.30-0.60 | 0.025 | 0.025 | 0.50-1.00 | 1.9-2.6 | 0.87-1.13 | |
| T91 | K90901 | 0.07-0.14 | 0.30-0.60 | 0.02 | 0.01 | 0.20-0.50 | 8.0-9.5 | 0.85-1.05 | V 0.18-0.25 |
| N 0.030-0.070 |
| Ni 0.40 max |
| Al 0.04max |
| Nb 0.06-0.1 |
| T92 | K92460 | 0.07-0.13 | 0.30-0.60 | 0.02 | 0.01 | 0.50 max | 8.5-9.5 | 0.30-0.60 | Ni 0.40 max |
| V 0.15-0.25 |
| B 0.001-0.006 |
| Nb 0.04-0.09 |
| N 0.030-0.070 |
| Al 0.04max |
| W 1.50-2.00 |
4. Mechanical Properties
| Mechanical Properties |
| Grade | T2 | T5 | T9 | T11 | T12 | T22 | T91 |
| Tensile strength, min: | |
| ksi | 60 | 60 | 60 | 60 | 60 | 60 | 85 |
| Mpa | 415 | 415 | 415 | 415 | 415 | 415 | 585 |
| Yield strength, min: | |
| ksi | 30 | 30 | 30 | 30 | 30 | 30 | 60 |
| MPa | 205 | 205 | 205 | 205 | 220 | 205 | 415 |
5. Package
Packed in steel bundle, seaworthy packing or as per customer’s
requirement.
6. Available Size Range
| OD | Thickness |
| mm | inch | mm | SCH |
| 21.3~60.3 | 1/2''~ 2'' | 2.11~11.07 | SCH10~XXS |
| *If the steel grades and size you are looking for are not listed
above, please contact us for further information. |
